Description

Ford TKX/TKO Installation Kit for 28-oz. Externally Balanced Small Block Ford EnginesDesigned for 28-ounce balance Small Block Ford engines using a TKX or TKO transmissionLight weight cast aluminum bellhousing and steel block plate provide a factory-like installation and appearanceBillet steel, 24.5lb, 157 Tooth externally balanced flywheel for light weight and strength26 spline, 10.5-inch clutch disk offers superior clamping force for engines up to 500hpRoller style pilot bearing offers improved shifting by reducing parasitic drag and transmission wearAdjustable Hydraulic Release Bearing offers reduced pedal effort and easy installationWorks with OE (original equipment) or MSD High Torque startersAll Hardware IncludedThese Holley Transmission Installation Kits come complete with everything you need to bolt a TKX or TKO transmission to a 28-ounce externally balanced small-block Ford engine. Built with a mixture of our best brands including Lakewood, Hays and Mr Gasket. Kits include: A roller pilot bearing, bellhousing with dust shield, billet steel flywheel, clutch and pressure plate, hydraulic release bearing, and all hardware needed to install these components.

Bellhousing Material: Aluminum

Disc Diameter: 10.5

Disc Material: Organic

Disc Style: Spring Hub

Engine Balance: External

Engine Make: Ford

Engine: Ford 289

Engine: Ford 302

Engine: Ford 351C

Engine: Ford 351W

Engine: Ford Small Block

Flywheel Balance: 28-ounce External

Flywheel Material: Billet Steel

Grade Type: Performance

Hardware: Steel

Input Shaft Diameter: 1-1/16″

Input Spline: 26

PILOT BEARING: Roller

Pressure Plate Style: Diaphragm

RELEASE BEARING: Hydraulic

Transmission: TKO Ford

Transmission: TKX Ford
