Description

600 CFM – 4150 – Mechanical Secondaries – Shiny – GasolineTumble polished shiny finish for good looksChevrolet small block 2×4, 671 blower calibrationContoured venturri inlet offers balanced airflow for increased horsepowerScrew in air bleeds for precision tuning capabilitiesDual 50cc accelerator pumps for additional fuel under initial accelerationDual feed fuel inlets for constant high volume fuel delivery4 corner idle allows you to precisely control your idle systemMechanical Secondaries for perfect off the line launchesBoost referenced power valve for proper enrichment under accelerationThrottle lever cut off for clearance on a sideways application100% wet-flow tested by Holley technicians to assure it arrives ready to run!By popular demand, Holley is expanding the draw-thru supercharger carburetor line to now include the XP series. Like the existing HP line, these are available in 600, 750, and 950 CFM flow rates and standard polished with black accents. The feature-laden XP includes a contoured venturi inlet for balanced air flow, screw in air bleeds for precision tuning capabilities, high flow billet metering blocks, billet base plate, and Dominator style fuel bowls which allow plumbing from either side.Supercharger XP carburetors also have a unique capability that allows their power valves to reference the intake manifold vacuum below the supercharger. This allows the power valve to operate as it should, based off intake manifold vacuum. A power valve provides further enrichment to the main metering system under load (low vacuum) conditions.Holley XP carburetors are the standard for square bore race carburetors. Race-Ready out of the box!

Barrels: 4

Body Color:Polished Aluminum

Body Finish: Polished

Body Material: Aluminum

Booster Design: Straight

Booster: Straight

Carburetor Material: Aluminum

Carburetor Use: Performance and Race

CFM Rating:600

Choke Type: None

Choke: None

Circuit Count:2

Color:Polished Aluminum

Condition: New

Cubic Feet Per Minute Rating: 600

Finish: Polished

Flange Shape: Square

Flange Type: Square/4150

Fuel Inlet: Dual

Fuel Type: Gasoline

Fuel: Gasoline

Grade Type: Performance

Linkage Attached: Yes

Marine Approved: No

Material: Aluminum

Model: XP-Series

Mounting Hole Quantity: 4

Primary Jet Diameter: 74

Primary Main Jet Size:74

Primary Power Valve: 10.5

Primary Pump Nozzle Size: 31

Secondary Barrel Type:Mechanical

Secondary Main Jet Size:74

Secondary Power Valve: 10.5

Secondary Pump Nozzle Size: 31

Spacer Included: No

Supercharger Compatible:Yes

System Type: Draw Thru

Throttle Bore Diameter:1.563 inch

Venturii Size: 1.250 inch
