Description

Ideally suited for bracket racers and weekend warriors alike, Q-Series carburetors are purpose-built for the dragstrip. To combat the g’s experienced during hard launches, Q-Series carbs are equipped with notched floats and secondary jet extensions. The high-flow aluminum main body isn’t just lightweight, but it also features recessed air bleed cavities for improved air flow. Die-cast venturi are machined to exacting tolerances for outstanding throttle response. Billet metering blocks ensure a uniform fuel curve, while throttle-bodies enhance durability. For those days when track conditions vary from one pass to the next, QFT’s QuickLink system makes adjusting the secondaries easy on models equipped with mechanical secondaries. The Q-Series is our most comprehensive line of carburetors, with applications available for use with gasoline, methanol, and E85 fuels, forced induction, drag race, circle track, and comes in both vacuum and mechanical secondary models.750 CFM – 4150 – Mechanical Secondaries – Shiny – E85â?¢Lightweight aluminum main bodyâ?¢Vacuum and mechanical secondary models availableâ?¢Aluminum fuel bowls with dual sight glass windowsâ?¢Billet metering blocks with 4-corner idle systemâ?¢Changeable idle feed and power valve channel restrictionsâ?¢Billet aluminum throttle body provides exceptional precision and strengthâ?¢PTFE coated and sealed shafts

Barrels: 4

Billet Color: Red

Body Color:Polished Aluminum

Body Finish: Polished

Body Material: Aluminum

Booster: Down Leg

Carburetor Use: Performance and Race

CFM Rating:750

Choke Type: None

Choke: None

Circuit Count:2

Color:Polished/Red

Condition: New

Cubic Feet Per Minute Rating: 750

Finish: Shiny

Flange Shape: Square

Flange Type: Square/4150

Fuel System: Carbureted

Fuel Type: E85

Fuel: E85

Gasket Or Seal Included: Yes

Grade Type: Performance

Linkage Attached: Yes

Marine Approved: No

Material: Aluminum

Model: Q-Series

Primary Main Jet Size:80

Primary Power Valve: 45

Primary Pump Nozzle Size: 35

Secondary Barrel Type:Mechanical

Secondary Main Jet Size:90

Supercharger Compatible:No

Throttle Bore Diameter:1-11/16 inch
